Type
4/5S EST
Number of doors
5
Wheelbase
2750 mm 108.3 in
Track: Front
1480 mm 58.3 in
Track: Rear
1460 mm 57.5 in
Length
4560 mm 179.5 in
Width
1695 mm 66.7 in
Height
1590 mm 62.6 in
Length:wheelbase ratio
1.66
Ground clearance
155 mm 6.1 in
Kerb weight
1360 kg 2998 lb
Fuel capacity
60 litres 13.2 UK Gal 15.9 US Gal
Bore
86.00 mm
Cylinders
S-4
Displacement
2 litre1998 cc(121.925 cu in)
Sump
Wet sumped
Compression ratio
10.50:1
Fuel system
direct petrol injection
Maximum power(JIS net)
155.1 PS (153.0 bhp) (114.1 kW)@ 6000 rpm
Specific output
76.6 bhp/litre1.25 bhp/cu in
Maximum torque(JIS net)
192.0 Nm (142 ft?�·lb) (19.6 kgm)@ 4000 rpm
bmep
1207.6 kPa (175.1 psi)
Specific torque
96.1 Nm/litre
Manufacturer
Toyota
Code
1AZ-FSE (D4)
Coolant
Water
Bore/stroke ratio
1
Unitary capacity
499.5 cc/cylinder
Aspiration
Normal
Compressor type
N/A
Intercooler
None
Catalytic converter
Y
Power-to-weight
112.5 bhp/ton
Engine location
Front
Engine alignment
Transverse
Drive
FWD
Steering
rack & pinion
Suspension
front I.MS.CS.ARB.
Wheels: Front
6JJ x 15
Wheels: Rear
6JJ x 15
Tyres: Front
195/65 R 15
Tyres: Rear
195/65 R 15
Brakes F/R
VeDi/Di-S
Transmission
CVT
Top gear ratio
0.43
Final drive ratio
5.18
RAC rating
18.3
Model code
DBA-ANE10G-HPXGH
year
2005
